Motic Panthera C2 Compound Microscope
In stock
SKU:
TMS-C2
Authorized Dealer
- UC Plan Objectives, 4X, 10X, 40X S, 100X S-oil
- Color-Corrected Infinity Optics
- 1W LED Variable illumination
- Ergonomic Design for ease of operation
- Focusable Abbe condenser N.A.0.90
- Recommended for Laboratories & Clinics
Summary
The Motic Panthera C2 Series is built for colleges, universities and medical school markets, setting a new price-performance standard for optical quality. The new series introduces innovative features like second-generation UC Plan optics, a new rackless stage movement and an advanced, modular LED illumination design. A 25-degree inclined Siedentopf binocular or trinocular head and 10X Widefield eyepieces round out an exceptional system.
Optics
The optical system is designed around a new generation of Color Corrected Infinity System UC Plan Achromatic objectives (4x, 10x, 40xS and 100xS Oil). These new lenses are multilayer-coated for improved color fidelity and image enhancement, rewarding student efforts with clear visual and digital results.
Accessories
Owners Manual, Hex Key, Dust Cover.
Specifications of Component Options
Select a component below to view related specifications.
-
Motic Panthera C2 Binocular LED Compound Microscope 1100104601136
Motic Panthera C2 Trinocular LED Compound Microscope 1100104601147
Motic Panthera C2 Trinocular Compound Microscope 50:50 Simple Phase package 1100104601162
Motic Panthera C2 Trinocular Compound Microscope 50:50 Phase package 1100104601171
Motic Panthera C2 Trinocular Compound Microscope + BMH4000X Camera Bundle 1100403300223
Motic Panthera C2 Trinocular Compound Microscope + BTI10 Camera Bundle 1100403300222 Product Details Brand Motic Motic Motic Motic Motic Motic Warranty - Limited Lifetime Warranty - - - - System System Type - Brightfield - - - - Optical Design - Infinity Corrected - - - - Number of Heads - Single Primary Head - - - - Head Head Type - Binocular - - - - Head Rotation - 360 Degrees - - - - Ocular Angle - 30° - - - - Diopter Adjustment - Dual - - - - Interpupillary Adjustment - Arc (Seidentopf) - - - - Interpupillary Adjustment Range - 55-75 mm - - - - Trinocular Type - Switchable Beam-Split - - - - Trinocular Tube Focusable? - No - - - - Parfocal - No - - - - Ocular Tube Diameter - 30 mm - - - - Body Nosepiece Orientation - Reversed - - - - Nosepiece Style - Quadruple (4) - - - - Focus Controls - Coarse & Fine - - - - Focus Mechanism - Rack & Pinion - - - - Focus Control Location - Dual Ambidextrous - - - - Focus Controls Graduated? - Yes - - - - Focus Control Safety Stop - Slip Clutch - - - - Stage Type - Mechanical XY - - - - Stage Features - Fingertip Controls - - - - Stage Range of Movement (XY) - 80mm x 30mm - - - - Stage Range Graduated? - Yes - - - - Configuration Includes Eyepieces? - Yes - - - - Included Eyepiece Quantity - 2 - - - - Included Eyepieces (X) - 10X - - - - Eyepiece Style - SWF Super Widefield (FN 20mm) - - - - Includes Eyecups? - No - - - - Min Standard Mag - 40X - - - - Max Standard Mag - 1000X - - - - Objectives Included Objectives (Qty) - 4 - - - - Objective Lens - Plan - - - - Included Objective Types - Brightfield - - - - Included Objectives Parfocal Adjustable? - No - - - - Objective 1 Description - EC PLAN 4X - - - - Objective 1 N.A. - 0.1 - - - - Objective 1 W.D. - 15.9 - - - - Objective 2 Description - EC PLAN 10X - - - - Objective 2 N.A. - 0..25 - - - - Objective 2 W.D. - 17.4 - - - - Objective 3 Description - EC PLAN 40X - - - - Objective 3 N.A. - 0.65 - - - - Objective 3 W.D. - 0.5 - - - - Objective 4 Description - EC PLAN 100X - OIL - - - - Objective 4 N.A. - 1.25 - - - - Objective 4 W.D. - 0.15 - - - - Condenser Condenser Type - Abbe Brightfield - - - - Condenser Features - Iris Diaphragm - - - - Condenser N.A. - 1.25 mm - - - - Illumination Illumination Type - LED - - - - Illumination Style - Transmitted - - - - Collector Type - Kohler - - - - Collector Features - Field Diaphragm - - - - Transmitted Light Type - LED - - - - Transmitted Light Specification - 3W 4500K Color Temp - - - - Transmitted Light Control - Variable - - - - Power Supply - 120V AC - - - - Compatibility Imaging Compatibility (with adapters) - 23mm - - - - Reticles Reticles Available? - No - - - - Accessories Included Extras - Immersion Oil - - - - Case Included? - No - - - -
