Omano
Omano Microscope - OMTM85L 40X-400X Dual Teaching LED Microscope
In stock
SKU:
OMTM-85
Authorized Dealer
- 40x, 100x, 400x magnification
- 2 oculars for teacher/student viewing
- LED illumination
- Coaxial coarse/fine focus for easy use
- Professional 1.25N.A condenser
- Plain stage - optional slide holder
- SAVE with optional 100x objective lens
- Lifetime Limited Warranty
- Recommended for K-12
Summary
The Omano OMTM85 is a well proven and popular student microscope where two people can view the specimen simultaneously without the need for a second microscope. This is particularly useful in a teaching environment and it is no surprise that the OMTM85 is consistently popular with Homeschoolers. The base model of this teaching microscope includes two WF10x eyepieces and three objectives. An optional 100x objective lens optical system and mechanical slide holder also available at a discounted price when purchased at the same time as the microscope.. Lifetime Limited warranty. Recommended for K-12, Home School.
Optics
The OMTM85 is characterized by crisp optics. Two wide fields, WF10x eyepieces (one for each ocular ), enable simultaneous viewing by both student and teacher. There are three achromatic, coated objective lenses (4x, 10x, 40xS) for magnification levels of 40x, 100x and 400x. A 100x spring oil immersion objective lens can be added at a discounted price when bought at the same time as the microscope.
Stage & Focus
A plain stage is included with an optional mechanical slide holder if purchased at the same time as the microscope. Coaxial coarse and fine focus controls are standard and enable significantly greater convenience than separate coarse and fine focus controls. Focusing has rack and pinion construction with slip clutch and rack stop to prevent damage to either the microscope or slides. There are both left and right hand focus controls.
Condenser & Illumination
The condenser is an Abbe 1.25 N.A with iris diaphragm and filter holder. Illumination is powered by a long-life LED.
Accessories
Dust cover, Manual.SAVE MORE when buying the optional 100x objective and/or the optional mechanical slide holder at the same time as the microscope. We recommend the slide holder for easier slide handling especially at higher magnifications of 400x and 1,000x.
Specifications of Component Options
Select a component below to view related specifications.
-
OMTM85L LED Teaching Microscope Product Details Brand Omano Warranty Omano Limited Lifetime Warranty System System Type Brightfield Optical Design DIN 160mm Number of Heads Dual-Head Teaching Head Ocular Angle 45° Diopter Adjustment Single Trinocular Tube Focusable? No Parfocal No Ocular Tube Diameter 23 mm Body Nosepiece Orientation Front-facing Nosepiece Style Quadruple (4) Focus Controls Coarse & Fine Focus Mechanism Rack & Pinion Focus Control Location Dual Ambidextrous Focus Controls Graduated? No Stage Type Fixed Stage Features Mechanical Stage Attachment Available Stage Range Graduated? No Configuration Includes Eyepieces? Yes Included Eyepiece Quantity 4 Included Eyepieces (X) 10X Eyepiece Style WF Widefield (FN 18mm) Includes Eyecups? No Min Standard Mag 40X Max Standard Mag 640X Objectives Included Objectives (Qty) 3 Objective Lens Achromatic Included Objective Types Brightfield Included Objectives Parfocal Adjustable? No Condenser Condenser Type Abbe Brightfield Condenser Features Iris Diaphragm Condenser N.A. 1.25 mm Illumination Illumination Type LED Illumination Style Transmitted Collector Type Simple Transmitted Light Type LED Transmitted Light Control Variable Power Supply Rechargeable Batteries (AA) or 120V AC - Plug-in Adapter Included Compatibility Imaging Compatibility (with adapters) 23mm Reticles Reticles Available? No Accessories Included Extras Dust Cover Case Included? No -
Achromatic Objective, 100xs Oil Immersion
Microscope Slide Holder
Microscope Soft Nylon Case - Small Product Details Brand Omano Omano Omano Warranty Omano Limited Lifetime Warranty - - Notes - Fits OM136C Series, OMTM85 Series. NOTE: Attachment may obstruct free rotation of objective lens turret. Function is not impaired, but please take care that you do not damage the lenses. - Optical Accessory Objective Lens Achromatic - - Objective Lens Power 100x - - Compatibility Compatible With - OM136C*, OMTM85* - -
DM200 JuniorCam 2.0MP Color Digital Microscope Eyepiece Camera
Summit KK3-1.3 1.3MP Windows-Only Color Digital Camera
Summit SK2-1.3X 1.3MP PC / MAC Compatible Digital Microscope Camera Product Details Brand OptixCam OptixCam OptixCam Warranty 1 Year 1 Year 1 Year Product Weight 2 2 2 Sensor Sensor Type CMOS CMOS CMOS Sensor Size 1/4 Inch 1/3 Inch 1/3 Inch Color/Monochrome Color Color Color Filter RGB Bayer Pattern RGB Bayer Pattern RGB Bayer Pattern Pixel Pitch 2.2 µm x 2.2 µm 3.6 µm x 3.6 µm 3.6 µm x 3.6 µm Sensor Color Depth 8bpp / 24bit RGB 8bpp / 24bit RGB 8bpp / 24bit RGB Scan Mode Progressive Progressive Progressive Signal to Noise Ratio 40 dB - 44 db Dynamic Range 50 dB - 71 db Peltier Cooling No No No Shutter Electronic Electronic Electronic Sensor Details - - Aptina MT9M111 CMOS Sensitivity - - 1.0V/Lux-sec (550nm) A/D Conversion - - 10-bit Parallel, 8-bit RGB to PC Camera Camera Mount Ocular Mount Ocular Mount C-Mount Resolution 1.3 Megapixel, 1280x1024 pixels 1.3 Megapixel, 1280x1024 pixels Camera Output Resolutions 1600X1200; 1280X960; 800X600; 640X480; 320X240 1280 X 1024; 640 X 512; 320 X 256 1280 X 1024; 640 X 512; 320 X 256 FPS @ Max Res 10 FPS @ 1600 X 1200 7.5fps @ 1280 x 1024 15@1280x1024; 26@640x512; 48@320x256 FPS @ Min Res 60 FPS @ 320 X 240 12.5fps @ 800 x 600 50fps @ 320 x 256 Camera Interface USB 2.0 USB 2.0 USB 2.0 White Balance Automatic Automatic Automatic Software Included Kopa Cam OptixCam K2View OptixCam K2View Driver API Compatibility DirectX DirectX DirectX Power Source USB USB USB File Formats JPEG JPEG BMP Exposure Control Automatic Automatic Automatic Exposure Time 3.9ms - 320ms 2000ms-0.14Ms 2000ms-0.14Ms Operating Temperatures 10°C ~ 50°C 10°C ~ 50°C 10°C ~ 50°C Operating Humidity 30% ~ 80% RH 30% ~ 80% RH 30% ~ 80% RH Storage Temperature -20°C ~ 60°C -20°C ~ 60°C -20°C ~ 60°C Other Details Included Accessories Software CD Software CD 0.5X 23mm DIN Adapter, Software CD Supported Operating Systems Windows 8 Windows 10 Windows 10 System Requirements 2GB RAM Recommended 2GB RAM Recommended 2GB RAM Recommended Certifications CE CE CE Cable Length 1.8m (8ft) 1.8m (8ft) 1.8m (8ft) Camera Warranty 1 Year 1 Year 1 Year Software Support 6 Months 6 Months 6 Months Compatibility Imaging Compatibility (with adapters) 23mm 23mm 23mm
| Brand | Omano |
|---|---|
| Warranty | Lifetime Limited Warranty |
| Recommended For | 0 |
| Global Industrial Description |
|
